Cudy 16 Port Gigabit Rackmount Switch

Cudy's CD-FS1018PS is a 16-Port Fast Ethernet switch with 16x 802.3af/at PoE ports, 2x Gigabit, and 1x SFP Uplink ports. The switch offers a 190W PoE budget, up to 30W per PoE port with a VLAN and Extender toggle switch. VLAN mode enables port isolation on ports 1-16 while Extender mode increases the transmission distance on ports 1-16 to 250m at 10Mbps. The watchdog function continuously monitors PoE connections. If an error is detected on the device, the switch immediately restarts the port.

SKU	CD-FS1018PS
Manufacturer	Cudy
Manufacturer Product Code	FS1018PS1
Download	Datasheet Download  Type Approval Exemption
Specifications	Ethernet Ports: 16x 10/100 ; 2x 10/100/1000 Hardware Button: VLAN ; Extender ; Default Max. Power Consumption: 10W Mounting: Rack-Mount Operating System: None Operating Temperature: 0°C to 40°C PoE Input: None PoE Output: 802.3af/at PoE on Ports 1~16 Power Input: 1x IEC Power Cord (Included) Serial Interface: None SFP Ports: 1x 1.25Gbps Supported Voltage Range: 100-240V Dimensions: 320 x 210 x 50mm Weight: 1.8kg
